Name: Garrett GT3071R (280-480 HP)
Brand: STM Tuned
SKU: garrett-gt3071r
Availability: InStock

🎉 Up to 70% Off Selected ItemsShop Sale

Home Store

Garrett GT3071R (280-480 HP)

Horsepower:

280 - 480

Displacement:

2.5L - 3.5L

Super Core Reference Data		Compressor				Turbine
Super Core PN	CHRA PN	Inducer	Exducer	Trim	A/R	Inducer	Exducer	Trim
836028-5001S	836000-0002	53mm	71mm	56	0.50	60mm	55mm	84
836028-5002S	836000-0002	53mm	71mm	56	0.50	60mm	55mm	84
836028-5004S	836000-0001	53mm	71mm	56	0.50	60mm	55mm	84
836028-5005S	836000-0001	53mm	71mm	56	0.50	60mm	55mm	84

Features:

Original GT series aerodynamics.
Internally wastegated turbine housing.
Non wastegated turbine housings available.
Ball bearing configuration with water cooled CHRA.
V-band turbine housing options.

Garrett® GT Series is the name that pioneered turbo technology and boosted drag racing and road racing teams to break hundreds of world records. The GT Series lineup is offered in both journal and ball bearing options, and sizes ranging from GT2052 to GT3582. The cast compressor wheels feature original GT Series aerodynamics and provide maximum durability and longevity. Internally wastegated turbine housing options are available in all GT Series sizes. Turbine kits are offered in open volute and twin scroll, and a variety of A/R and flange configurations. For any performance need, GT Series turbochargers have you covered.

Select Compressor Housing (Inlet and Outlet)

Select Turbine Housing Option (A/R, Inlet, Outlet)

From $332.45

Original: $949.87

-65%

Garrett GT3071R (280-480 HP)—

$949.87

$332.45
